Technical Specifications

Accuracy: 0.025 mm (0.0009 in)

Volumetric accuracy: 0.020 mm + 0.040 mm/m (based on part size) (0.0008 in + 0.0005 in/ft)

Acceptance test: Based on VDI/VDE 2634 part 3

Measurement capabilities (at a working distance of 0.3 m (1 ft))

• Pin: 0.750 mm (0.0295 in)

• Hole: 1.250 mm (0.0492 in)

• Step: 0.025 mm (0.0009 in)

• Wall: 0.500 mm (0.0197 in)

Measurement resolution: 0.025 mm (0.0009 in)

Mesh resolution: 0.100 mm (0.0039 in)

Measurement rate: 1,300,000 measurements/s

Light source: 22 blue laser lines(4) (+1 extra line)

Working Distance: 200 to 450 mm (7.9 × 17.7 in)

Depth of field: 250 mm (9.8 in)

Part size range (recommended): 0.05-4 m (0.15-13.1 ft)

Software: VXelements

Output formats: .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf

Compatible software: 3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Metrologic Group (Metrolog X4), New River Kinematics (Spatial Analyzer), Verisurf, Dassault Systèmes (CATIA V5, SOLIDWORKS), PTC (Creo), Siemens (NX, Solid Edge), Autodesk (Inventor, PowerINSPECT)

Weight: 0.94 kg (2.1 lb)

Dimensions: 79 x 142 x 288 mm (LxWxH) (3.1 x 5.6 x 11.3 in)

Connection standard: 1 X USB 3.0

Operating temperature range: 5-40 °C (41-104 °F)

Operating humidity range: 10-90% (non-condensing)

Certifications: EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive), compatible with rechargeable batteries (when applicable), IP50, WEEE
